Monoprice 25ft 24AWG CL2 Standard HDMI® to DVI Adapter Cable Black

Digital Visual Interface (DVI) is the standard interface for a high-performance connection between PCs and flat panel displays, digital CRT displays, projectors, and HDTV. The DVI-D Digital Cable delivers the high-performance, high-bandwidth interface needed for video displays of today while leaving headroom for the products of tomorrow. These precision-engineered cables are fully compliant with the DVI standard defined by DDWG (Digital Display Working Group). The DVI-D dual link configuration provides enough bandwidth for resolutions up to 2048 x 1536 and allows high speed digital transmission up to 9.9 Gbps.

Specs & Features

Connector Type: DVI-D male to DVI-D male
Signal Type Digital
Connector Finish: Gold
Length: 25ft
Gauge: 24AWG
Pin Configuration 24 + 1
Conductor Plating: None
Shielding level: Triple
Shielding type: EMI
Ferrite Cores: Yes
1080p support Yes
Bandwidth: Dual Link
Maximum Resolution 2048 x 1536
Min Clock Freq. 21.76 Mhz
Max Clock Freq 165 MHz x 2
Max Throughput 9.9 Gbps
Pixels per cycle 2
Bits per Pixel 24
DDWG Compliant: Yes
HDCP Compliant: Yes
ROHS Compliant Yes
UL Certified Yes


UL Specs
Digital
UL File #: E119932
UL Style #: 20276
CL2 (In-Wall): Yes
VW-1: Yes
Voltage Rating: 30V
Temperature Rating: 80° C
